Pamex Konetik Keyless Leverset

Pamex Konetic Electronic Keyless Leverset

– Fits standard door prep with 2 1/8″ dia. bore hole and 1″ cross bore.
– ANSI/BHMA 117.1, Grade 2
– UL10C and S104 (20 minutes)
– Programmable via a tablet with Bluetooth 4.0 or higher
– 5 Pin Kwikset Keyway Standard, also available with Schlage 5 Pin SC (C) Keyway
– Key Fob / Card Entry
– Reversible – fits right handed or left handed doors
– Uses 4 AA Batteries (average lifecycle 1 year)
– ADA Compliant
– Fit 1-3/8” to 1-3/4” standard
– 1-1/8” x 2-1/4” square corner standard
(other options available)
– 2-3/4” x 1-1/8” square corner T-strike standard (other options available)
– Adjustable UL deadlatch standard (other options available)
– Frequency 13.56MHz RFID
– Read Range 1 cm (ISO Card); MIFARE: S70 EV1
– Operating temperature -30 to 120F
– 6000 Events
– Code Compliance – ANSI/BHMA Grade 2 certified / ANSI 117.1 for ADA / UL10C and S104 (20 minutes)

Pamex Konetik Keyless Lever Measurements and Specs
Pamex Konetik Keyless Lever Installation Instructions
